Recommended truck model: Youngman JNP3250FD

JNP3250FD

Driveline

6×4

Wheelbase

3600+1350

Overall dimension

length

8110

width

2490

height

3450

Track

FR/RR

2006/1864

Overhang

FR/RR

1525/1685

Kerb weight

12450

GVW

25000

Front axle /Front/Rear axle

FR/RR

7000/18000
Two axles in parallel

Max speed

Km/h

88

Min Turing diameter

m

18.7

Engine style

Model

MAND2866LF27

Type

Turbine intercooling, EDC diesel engine

Number of cylinder

In line 6

Displacement

11.967

Emission standard

Euro II

Max output power

265（360）/1700~1900

Max torque (kg.m/rpm)

1700/900-1400

Clutch

Type

Hydraulic control air assistant

Single dry plate, hydraulic control with air pressure assistance, diaphragm spring

Material

non-asbestos

Transmission

Model

9JS200TA

Type

9 forward gear, 1rear gear

Gear device

single role, mechanical, tele-operation device

Rear axle

Model

YOUNGMAN

Type

floating

Permissible load

kg

18000

speed ratio

5.73

Front axle

Type

 Youngman

Permissible load

kg

7000

Tyre

Type

Single tyre on the front, double on the rear.

Tyre

12.00-20

Braking   system

Pedal brake

type

Dual-circuit air system, F/R drum brake, with ABS

Valve brake

WEVB system in engine, “butterfly” Valve

Suspension

Type

F/R

Steel board and spring/ more slice of steel board and spring, suspension for balance

shock-absorber

Dual-oriented folding shock-absorber and stable horizontal bar in front axle

Tank

material

aluminum alloy

Capacity

liter

500L

Other

Low roof single bed luxury floating cabin of MAN FA2000 style. High quality pressing alloy steel which is fine and yield strengthening is adopted into vehicle frame. The alloy steel, which is wide on the front and narrow on the rear and without bolt on both interface of up and down and auto fitting, is molded immediately.

Certification for China Compulsory Product Certification, Euro III, and Oil-reducing, high-efficient, environment-friendly.
European brand-new design for frame construction. European EEC regulation for cabin greatly improves safety of driver. Shock avoiding and floating cabin makes great progress in security performance.
Man technology is adopted into our company. The immediately molded alloy steel give high capability in sealing, rain-avoiding, anti-dust, dust-proof.
Optimizing configuration adjust is made by German senior expert for the whole truck. It gives 15% more than traditional truck in efficiency and reduces the oil-consume. And it gives 40% more than traditional truck in loading capacity and reduces 8 to 15 percentage oil-consume. Furthermore, the whole body of truck which makes a great reduction in both windward area and coefficient of air resistance had passed the test for wind whole.
